Detection method | pump suction |
Battery | 3.6V or 7.2V Li-ion rechargeable battery |
Direct reading | real-time value |
Display | Large screen LCD |
Alarm | sound, light alarm |
KP826-B pump multi-gas detector using dot matrix display technology, and can be configured with single gas sensor or multiple gas sensors. User can be freely choose single, double, triple, four-in-one or optional four kinds of toxic gas sensor for testing.
KP826-B has large LCD screen, sound and light alarm. It can be applied in adverse working environment for detecting dangerous gases and promptly alerts operator. This product is suitable for chemical, pharmaceutical, municipal, water treatment, telecommunications, archeology, laboratories, cold storage, wine and other places.
The below gases are available
Gas detected |
Measuring Range |
Optional Range |
Resolution Ratio |
Response Time |
LEL -combustible gas |
0-100%LEL |
0-100%VOL(Infrared or catalytic ) |
1%LEL/1%vol |
≤10s |
carbon monoxide |
0-1000PPm |
0-500/2000/5000PPm |
0.1/1PPm |
≤10s |
TVOC |
0-100PPM |
0-100PPM |
0.1PPm/1PPM |
≤15s |
hydrogen |
0-100%LEL |
0-1000PPM |
1%LEL/1PPM |
≤15s |
natural gas |
0-100%LEL |
0-100%LEL |
1%LEL |
≤10s |
Oxygen-O2 |
0-30%VOL |
0-30%、0-100%VOL |
0.1%vol |
≤10s |
ozone |
0-10PPm |
0-20、100PPm |
0.01PPm/0.1PPM |
≤15s |
hydrogen sulfide-H2S |
0-100PPm |
0-50、200、1000PPm |
1/0.1PPm |
≤10s |
Methane-CH4 |
0-100%LEL |
0-100%VOL |
1%LEL/1%vol |
≤10s |
fluorine |
0-10PM |
0-1、10PPM |
1/0.1PPm |
≤15s |
hydrogen chloride |
0-20PPm |
0-20/50PPm/100PPM |
0.01/0.1PPm |
≤15s |
Nitrogen-N2 |
0-30%VOL |
0-30%VOL、100%VOL |
0.1%LEL/1PPM |
≤10s |
hydrogen |
0-100%LEL |
0-1000PPm |
1%LEL/0.1PPm |
≤15s |
chlorine |
0-20PPm |
0-10、100PPm |
0.1PPm |
≤15s |
ammonia gas |
0-100PPm |
0-50、500、1000PPm |
1/0.1PPm |
≤15s |
oxynitride |
0-20PPm |
0-50、1000PPm |
0.1/1PPm |
Detection method: |
pump suction |
Battery |
|
Battery working time: |
15 hours of continuous work (combustible gas) |
Continuous work |
around 200 hours (except combustible gas) |
Sensor working principle |
electrochemical for oxygen / toxic gas sensor and catalytic for combustible gas |
Display |
Large screen LCD |
Alarm |
sound, light alarm |
Direct reading |
real-time value |
Explosion-proof mark |
Ex ib IIB T3 Gb |
Protection grade |
IP65 |
Working humidity: |
5-90% RH |
Working temperature |
-20 ∽ 60 ℃ |
Size |
180mm (length) × 113mm (width) × 82mm (height) |
Weight |
1Kg (with charger, without code case) |
